Casing Specification
Series
Case Type
Dimension
505 x 230 x 506 mm
(19.9 x 9.1 x 19.9 inch)
Weight
Side Panel
Color
Material
Cooling System
Front(intake): 200 x 200 x 30 mm ARGB PWM fan (1000rpm, 35.5 dBA) x 2
Rear(exhaust): 20 x 120 x 25 mm ARGB PWM fan (1500rpm, 27.2 dBA) x 1
Drive Bays
Expansion Slots
Motherboard
6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX),
12” x 9.6” (ATX), 12” x 13” (E-ATX)
I/O Port
PSU
Fan Support
Front: 3 x 120mm, 2 x 120mm, 1 x 120mm
3 x 140mm, 2 x 140mm, 1 x 140mm
2 x 200mm, 1 x 200mm
Top: 3 x 120mm, 2 x 120mm, 1 x 120mm,
2 x 140mm, 1 x 140mm
1 x 200mm
Right(M/B Side): 3 x 120mm, 2 x 120mm, 1 x 120mm (Without HDD Rack)
Rear: 1 x 120mm
Radiator Support
Front: 1 x 360mm, 1 x 240mm, 1 x 120mm
1 x 280mm, 1 x 140mm
Top: 1 x 360mm, 1 x 240mm, 1 x 120mm
1 x 280mm, 1 x 140mm
Right(M/B Side): 1 x 360mm, 1 x 240mm, 1 x 120mm(Without HDD Rack)
Rear: 1 x 120mm
Clearance
CPU cooler height limitation: 175mmVGA length limitation: 280mm(With reservoir)
400mm(Without reservoir)
PSU length limitation: 200mm
